Lever set on backplate Brooklyn
UEL59 LA60 71
| Angle | 28 degree |
| Shape | rectangular |
| Handing required | Yes |
| Material | stainless steel |
| Designer | Itamar Harari |
| Width | 2 3/8" (60mm) |
| Strike plate | T-Strike, Lip-Strike |
$519,00Technical data
| Article number | UEL59 LA60 71 |
| List price | $519,00 |
| Function | single cylinder entry |
| Finish | satin stainless steel |
| Shape | rectangular |
| Material | stainless steel |
| Backset | 2 3/8" (60mm) |
| Angle | 28 degree |
| Strike plate | T-Strike, Lip-Strike |
| Minimum standard door thickness | 1 9/16" (40mm) |
| Maximum standard door thickness | 2 3/8" (60mm) |
| Screw type | visible fixings |
| Handing required | Yes |
| Height | 9 7/8" (250mm) |
| Width | 2 3/8" (60mm) |
| Thickness | 7/16" (12mm) |
| Lock hole spacing | 5 1/2" (140mm) |
| Key way | C-Keyway |
Downloads
Files
Related products
UEL59 PB60 71 - Brooklyn, privacy, Backset 2 3/8"
UEL59 PAT60 71 - Brooklyn, patio, Backset 2 3/8"
UEL59 PAS60 71 - Brooklyn, passage, Backset 2 3/8"
UEL59 DUM 71 - Brooklyn, dummy, trim only
ES3 1000 71 - pull handle (L:39 3/8 ", CtC:31 1/2 ")
ES13Q 1000 71 - pull handle (L:39 3/8 ", CtC:31 1/2 ")
EPDQ 71 - pocket door set
EPD 71 - pocket door set
Please note: Karcher Design products are designed and measured in metric.
Imperial measurements are close approximations to the actual metric dimenions.
